| Layers |
 Single Layer
Double Layer
4 Layer
6 Layer
8 Layer
10 Layer
12 Layer
14 Layer
|
|
|
|
| |
| Board Thickness |
| 0.2mm – 3.2mm |
|
|
|
| |
| Laminates |
| FR-1 , FR-4 , CEM-1 , CEM-3 , HIGH TG , Aluminium, Halogen Free , High CTI |
|
|
|
| |
| Laminate Supply |
| KINGBOARD ; CHANGCHUN ; ETERNAL ; SHENGYI ; DOOSAN |
|
|
|
| |
| Copper Thickness |
| Outer Min. Copper thickness H oz cu , Max. copper thickness 4 oz cu |
| Inter Min. Copper thickness H oz cu , Max copper thickness 3 oz cu |
|
|
* PCB Layout Copy Available |
| |
| Minimum Hole Size : 0.2mm |
|
|
|
| |
| Minimum Line Space and Line Width : 4 mil |
|
|
|
| |
| Surface Finishing |
| OSP, Hot Air Leveling, Lead Free HAL, Immersion Tin, Immersion Silver, Immersion Gold, Flash Gold |
|
|
|
| |
| Special Technology |
| Gold Finger, Peelable Mask, CNC V-Cut, Carbon, Blind / Buried Via, BGA Boards, Impedance Control |
|
|
|
| |
| CAD Software |
| Auto CAD, CAM 350, Eagle, GC Gerber, PCB File, ProTel |
|
|
|
| |
| PCB Application |
| LED, LCD Monitor, Telecommunication Equipment ; Computer Peripheral ; Testing & Measuring Equipment |
| Medical Apparatus ; Musical Instrument ; Power Supply ; Amplify ; Controller ; Security Alarm |
|
|
|
| |
| PCB Assembly Services |
| SMT Chip Size
- Down to 0402 |
| QFP and BGA fine pitch - Down 0.4 mm |
| SMT Line Output Rate - 1000K Chips Per Day |
|
|
| |
|
|
|
|
|
 |
|
|
